Ergnomic operation

Reduced footprint

Ergnomic operation

Reduced footprint

The Advantages

  • Diagonal and parallel joining methods
  • Screen dialog system under Windows
  • Data management via database
  • Welding bead limiting device, heated
  • Individually programmable welding parameters
  • Removal handling system (optional)
  • Mounting frame welding with inner stop (optional)
  • Integration into a welding/cleaning line possible

The Advantages

  • Diagonal and parallel joining methods
  • Screen dialog system under Windows
  • Data management via database
  • Welding bead limiting device, heated
  • Individually programmable welding parameters
  • Removal handling system (optional)
  • Mounting frame welding with inner stop (optional)
  • Integration into a welding/cleaning line possible

Technical Data

Component size min 325 x 320 mm
Component size max. 4000 x 2600 mm
Profile depth min 30 mm (clamping distance 120 mm)
Profile depth max 120 mm (clamping distance 120 mm)
Profile view width max 130 mm
